Aaronia SPECTRAN V6 5G Series Realtime Spectrum Analyzers

Benefits of the SPECTRAN V6 5G 53 GHz Realtime Spectrum Analyzers

• Frequency range up to 53 GHz, RTBW up to 60 MHz.
• Very compact USB PC-module formfactor.
• Sweep speed 500 GHz/s, option up to 3 THz/s.

Aaronia SPECTRAN V6 5G Series Realtime Spectrum Analyzers

Models SPECTRAN V6 V5G 100XA-30, 200XA-50

The Aaronia SPECTRAN V6 5G series are real-time spectrum analyzers specifically designed for monitoring 5G networks, detecting even the shortest signal interference or performance degradation. The devices offer a great price/performance ratio as well as the number of available additional functions. The analyzer scans 6 GHz in less than 10 ms (3 THz/s). Due to its weight and dimensions, the SPECTRAN V6 5G is ideal for measurements in the field and in the lab. The RTSA-Suite PRO software has a modular design that lets you select exactly those extensions that are really needed.

• Frequency range 250 MHz...7.125 GHz, 24...53 GHz.
• Scans 6 GHz in less than 10 ms.
• Unlimited, continuous, true 24/7 I/Q streaming.
• Extraordinary dynamic range with a 16 bit ADC at 2 GS/s.
• Sample rate of 500 MS/s (16 bit Dual 256 MS/s I/Q-Data).
• FPGA 930 GMAC/s.
• FFT rate 960 Million FFT-points/s (120 Million FFTs/s).
• Stackable accessories.
• Compact and lightweight.
• Power via USB (10 W).
• Included software:
  RTSA-Suite PRO spectrum analysis software with regular updates.
  Fully remote controllable via platform independent HTTP based API.
  Native C++ SDK for Windows and Linux.
  Community plugins for GNU Radio, SDRAngel, SDR++ and many more.
• Made in Germany.

Model Overview
