PicoScope 4262 Very-High-Resolution Oscilloscope - a Digital Oscilloscope for the Analog World
The PicoScope 4262 is a dual-channel, 16 bit very-high-resolution oscilloscope with an integrated low-distortion signal generator. With its 5 MHz bandwidth, it can easily analyse audio, ultrasonic and vibration signals, characterise noise in switched mode power supplies, measure distortion and perform a wide range of precision measurement tasks.
- Low noise.
- 2 channels.
- 16 MS buffer memory.
- High precision, high resolution 16 bit.
- 10 MS/s sampling.
- 5 MHz bandwidth.
- Variety of advanced triggering features.
- Integrated, low-distortion function generator (sine, square, triangle, DC; DC...20 kHz; ±1 V) and arbitrary waveform generator (192 kHz upate rate, 20 kHz bandwidth; 16 bit resolution; 4 kS buffer).
- USB 2.0 interface. USB-powered.
- Kit incl. probes.
Model Overview
| Model | PicoScope 4262 (PP799) |
| Channels | 2 |
| Bandwidth | 5 MHz |
| Resolution | 16 bit |
| Max. sample rate | 10 MS/s |
| Buffer memory | 16 MS |
| Waveform generator | 20 kHz function generator: Sine, square, triangle, DC; arbitrary waveform generator: 192 kHz upate rate, 20 kHz bandwidth; 16 bit resolution; 4 kS buffer) |
| Interface | USB 2.0, USB-powered |
| Dimensions (mm) | 210 x 135 x 40 (incl. BNC), max. 0.5 kg |
Included: USB oscilloscope, USB cable, 2x probes MI007, ▸PicoScope 7 software and user manual (download).
