Tabor Lucid R/Rackmout Modular RF Signal Generators up to 12GHz

Benefits of the Lucid R RF Signal Sources, up to 16-Channel Rack Modules

• Rack-mountable for high channel density. Extremely fast switching speed <100 µs and maximum output power +15 dBm.
• Exceptionally low phase noise -145 dBc/Hz at 100 MHz and 10 kHz offset.
• Remotely programmable via MATLAB, Python, LabVIEW and other software programming environments.

Tabor Lucid R/Rackmout Modular RF Signal Generators up to 12GHz

Modeld LS3081/3082/3084/30816R, LS6081/6082/6084/60816R, LS1291/1292/1294/12916R

The Tabor LS3081/2/4/16R, LS6081/2/4/16R and LS1291/2/4/16R from the Lucid series are rack-mountable RF signal generators up to 12 GHz for high channel density. The Lucid series feature 3, 6 and 12 GHz 1-, 2-, 4, and 16-channel models, all sharing the very same industry leading highlighted features, in a 19" module. Featuring extremely fast switching speed, superior signal integrity and purity, all the necessary modulated signals for analog communication systems, with built in USB and Ethernet/LAN interface, the Lucid Series is designed to meet today’s most demanding specifications, needed from the R&D benches to the production lines.

• 3, 6, 12 GHz RF analog signal generators, 1, 2, 4, or 16 channels.
• Exceptionally low phase noise of -145 dBc/Hz at 100 MHz and 10 kHz offset.
• Extremely fast switching speed of <100 µs.
• AM, FM, PM sweep and pulse modulation.
• Remotely programmable via MATLAB, Python, LabVIEW and other software programming environments.
• USB and Ethernet/LAN integrated interfaces.
• Rack-mountable module platform for high channel density in 19" systems.
• Multi instrument synchronization capability.

Model Overview
