ITECH IT7600 High-power Programmable AC Power Supply

Benefits of the IT7600 Series AC Power Supplies up to 54 kVA

• Real-time waveforms of voltage and current under single unit or parallel mode.
• Maximum power up to 54 kVA, voltage 300 V/600 V.
• Versatile harmonic simulation capability, up to 50th harmonic simulation.

ITECH IT7600 High-power Programmable AC Power Supply

Models IT622, IT624, IT625, IT626, IT627, IT628(L), IT630, IT632, IT634, IT636

The ITECH IT7600 series high performance programmable AC power supplies adopt advanced digital signal processing technology, with frequencies up to 10...5000 Hz, a built-in all-round power meter and large-screen oscilloscope function. The devices deliver power up to 54 kVA and support master-slave parallel, which can provide high-capacity single-phase or three-phase AC outputs. Some models can be upgraded to 600 VAC by an optional boosting module. The IT7600 series has a built-in arbitrary waveform generator to simulate the harmonic and a variety of arbitrary waveforms output as well as versatile exchange measurement and analysis functions. The IT7600 devices can be widely used in many areas, such as new energy, home appliances, power electronics, civil avionics, the development and application of IEC Standard test, mining equipment test and so on.

• High power AC power supplies.
• 7"/17.8 cm DSO function, which can display real-time waveforms of voltage and current under the single unit or parallel mode.
• Built-in powerful single-phase or three-phase AC power meter.
• Output frequency up to 10...5000 Hz, output variable rate of voltage or frequency is adjustable.
• Maximum power up to 54 kVA.
• Voltage up to 300 V/600 V (optional boosting module IT-E760A).
• Realize AC, DC, AC+DC output modes, AC+DC can realize simulating distortion of DC voltage (IT7628L, IT7630, IT7632, IT7634, IT7636 only support AC mode).
• Simulate arbitrary waveform output, support CSV format to import waveform.
• Built-in various waveform database.
• Master-slave paralleling makes multi-module output equalized current synchronously.
• Support single/three-phase output, and can simulate unbalanced three phase output (IT7622, IT7624, IT7626 can parallel multiple units to achieve single/three-phase output. IT7627, IT7628 can achieve single/three-phase switching output).
• Versatile harmonic simulation capability, up to 50th harmonic simulation (10...500 Hz).
• Versatile harmonic analysis function, which can measure up to 50th voltage and current harmonic (10...500 Hz).
• LIST mode can simulate civil use AC network, achieve simulation of instantaneous power interruption.
• The output waveform start/stop phase angle can be set.
• Support remote sense compensation function, which can improve measurement accuracy.
• Relay control output function, which can achieve electrical isolation between DUT and the source.
• Sweep function, which can test the efficiency of switching power supply and catch the voltage and frequency when reaching maximum power point.
• OTP, OCP (including peak and RMS values), OPP.
• Built-in USB, RS232, Ethernet/LAN, optional GPIB/IEEE488, CAN communication interface. Front panel USB for importing/exporting file, data storage function.

Model Overview
