HIKMICRO SP-Series Handheld Thermal Cameras

New
HIKMICRO SP series handheld thermal cameras
starting € 10.708,81
including VAT free shipping (Germany)
min Quantity
1 piece
Unit price
base price
Variants
technical Question?
recommend by email
close
Please fill in all fields.
Question Type
Your E-mail Adress
My Question:
Please validate that you are not a robot.
Description
Accessories
Files/Downloads

Benefits of the SP40L/H, SP60L/H, SP120H Thermo/Visual Cameras -20...+650°C/-40...+2200°C

  • High-performance handheld thermal cameras with high sensitivity (NETD <30 or 20 mK).
  • Thermal resolution up to 640x480 (307,200 pixels) or 1280x1024 (SP120H).
  • 90° rotating screen and 180° rotating lens design.

HIKMICRO SP-Series Handheld Thermal Cameras

Series SP40, SP40H, SP60, SP60H, 640x480 IR Cameras with Visual 8 MP Camera, SP120H 1280x1024

The HIKMICRO SP series are high-performance handheld thermal cameras. The are ideal for industrial, predictive, oil and gas, and utility maintenance inspections. HIKMICRO SP series has a high sensitivity (NETD <30 mK, SP120H: <20 mK) and high resolution (640x480, SP120H: 1280x1024) HIKMICRO VOx detector. The temperature calibration is up to 2200°C (SP60H, SP40H, SP120H), or 650°C (SP60L, SP40L). This flexible and ergonomic thermal imagers provide an electronic viewfinder and a 180° rotating lens, making long-day outdoor inspections easier. Advanced features help thermal imaging professionals to easily survey equipment and find signs of malfunction, such as GPS and compass annotations, continuous digital zoom, and 1-tap level and span. Connect HIKMICRO Viewer App or HIKMICRO Analyzer software to transfer, analyze, and share pictures, and generate reports for free.

  • Thermal resolution:
    SP120H: 1280x2014 (2,577,929 pixels).
    SP60H, SP60L: 640x480 (307,200 pixels).
    SP40H, SP40L: 480x360 (172,800 pixels).
  • NETD <30 mK, SP120H: <20 mK (at 25°C, F#=1.0).
  • Temperature measurement range:
    SP60H, SP40H, SP120H: -40...+2200°C (-40...3992°C).
    SP60L, SP40L: -20...+650°C (-4...+1202°F).
  • Accuracy:
    SP60H, SP40H, SP120H: Max. ±1°C (±1.8°F): 0...+100°C (+32...+212°F); ±1%: +100...+150°C (+212...+302°F).
    SP60L, SP40L: Max. ±2°C/3.6°F, ±2%.
  • 90° rotating screen and 180° rotating lens design.
  • 1024x768 OLED electronic viewfinder and auto-brightness 5"/12.7 cm color LCD display.
  • 1.x to 12.x continuous digital zoom.
  • Manual, automatic, and 1-tap level and span.
  • GPS and compass annotation functions.
  • 30 Hz image frequency.
  • Up to 4 hours continuous running.

Model Overview

ModelPart numberIR resolutionField of view (FOV)Focus, NETDImage frequencyVisible cameraObject temperature rangeStorage media (SD)Display, HDMIBatteryInterfaces
SP60-L25HM-TP96-Q/W-SP60-L25640x48024.8°x18.7°Auto/manual focus,
NETD <30 mK		30 Hz8 MP-20...+650°C, ±2°C/±2%64 GB5"/12.7 cm 1280x720 LCD touch screen with 90° tilting,
1024x768 OLED viewfinder;
HDMI		ReplaceableGPS,
Wi-Fi, Bluetooth, USB type C,
laser range finder
SP60-L50HM-TP96-Q/W-SP60-L50640x48050°x37.3°Auto/manual focus,
NETD <30 mK		30 Hz8 MP-20...+650°C, ±2°C/±2%64 GB5"/12.7 cm 1280x720 LCD touch screen with 90° tilting,
1024x768 OLED viewfinder;
HDMI		ReplaceableGPS,
Wi-Fi, Bluetooth, USB type C,
laser range finder
SP60-L12HM-TP96-Q/W-SP60-L12640x48012°x9°Auto/manual focus,
NETD <30 mK		30 Hz8 MP-20...+650°C, ±2°C/±2%64 GB5"/12.7 cm 1280x720 LCD touch screen with 90° tilting,
1024x768 OLED viewfinder;
HDMI		ReplaceableGPS,
Wi-Fi, Bluetooth, USB type C,
laser range finder
SP60-L8HM-TP96-Q/W-SP60-L8640x4808°x6°Auto/manual focus,
NETD <30 mK		30 Hz8 MP-20...+650°C, ±2°C/±2%64 GB5"/12.7 cm 1280x720 LCD touch screen with 90° tilting,
1024x768 OLED viewfinder;
HDMI		ReplaceableGPS,
Wi-Fi, Bluetooth, USB type C,
laser range finder
SP60-L12/50HM-TP96-Q/W-SP60-L12/50640x48012°x9° and
50°x37.3°		Auto/manual focus,
NETD <30 mK		30 Hz8 MP-20...+650°C, ±2°C/±2%64 GB5"/12.7 cm 1280x720 LCD touch screen with 90° tilting,
1024x768 OLED viewfinder;
HDMI		ReplaceableGPS,
Wi-Fi, Bluetooth, USB type C,
laser range finder
SP60-L8/25HM-TP96-Q/W-SP60-L8/25640x48024.8°x18.7° and
8°x6°		Auto/manual focus,
NETD <30 mK		30 Hz8 MP-20...+650°C, ±2°C/±2%64 GB5"/12.7 cm 1280x720 LCD touch screen with 90° tilting,
1024x768 OLED viewfinder;
HDMI		ReplaceableGPS,
Wi-Fi, Bluetooth, USB type C,
laser range finder
SP60-L12/25HM-TP96-Q/W-SP60-L12/25640x48024.8°x18.7° and
12°x9°		Auto/manual focus,
NETD <30 mK		30 Hz8 MP-20...+650°C, ±2°C/±2%64 GB5"/12.7 cm 1280x720 LCD touch screen with 90° tilting,
1024x768 OLED viewfinder;
HDMI		ReplaceableGPS,
Wi-Fi, Bluetooth, USB type C,
laser range finder
SP60-L25/50HM-TP96-Q/W-SP60-L25/50640x48024.8°x18.7° and
50°x37.3°		Auto/manual focus,
NETD <30 mK		30 Hz8 MP-20...+650°C, ±2°C/±2%64 GB5"/12.7 cm 1280x720 LCD touch screen with 90° tilting,
1024x768 OLED viewfinder;
HDMI		ReplaceableGPS,
Wi-Fi, Bluetooth, USB type C,
laser range finder
SP60H-L25HM-TP96H-Q/W-SP60H-L25640x48024.8°x18.7°Auto/manual focus,
NETD <30 mK		30 Hz8 MP-40...+2200°C, ±1°C/±1% (0...+150°C) or
±2°C/±2%		64 GB5"/12.7 cm 1280x720 LCD touch screen with 90° tilting,
1024x768 OLED viewfinder;
HDMI		ReplaceableGPS,
Wi-Fi, Bluetooth, USB type C,
laser range finder
SP60H-L50HM-TP96H-Q/W-SP60H-L50640x48050°x37.3°Auto/manual focus,
NETD <30 mK		30 Hz8 MP-40...+2200°C, ±1°C/±1% (0...+150°C) or
±2°C/±2%		64 GB5"/12.7 cm 1280x720 LCD touch screen with 90° tilting,
1024x768 OLED viewfinder;
HDMI		ReplaceableGPS,
Wi-Fi, Bluetooth, USB type C,
laser range finder
SP60H-L12HM-TP96H-Q/W-SP60H-L12640x48012°x9°Auto/manual focus,
NETD <30 mK		30 Hz8 MP-40...+2200°C, ±1°C/±1% (0...+150°C) or
±2°C/±2%		64 GB5"/12.7 cm 1280x720 LCD touch screen with 90° tilting,
1024x768 OLED viewfinder;
HDMI		ReplaceableGPS,
Wi-Fi, Bluetooth, USB type C,
laser range finder
SP60H-L8HM-TP96H-Q/W-SP60H-L8640x4808°x6°Auto/manual focus,
NETD <30 mK		30 Hz8 MP-40...+2200°C, ±1°C/±1% (0...+150°C) or
±2°C/±2%		64 GB5"/12.7 cm 1280x720 LCD touch screen with 90° tilting,
1024x768 OLED viewfinder;
HDMI		ReplaceableGPS,
Wi-Fi, Bluetooth, USB type C,
laser range finder
SP40-L19HM-TP94-Q/W-SP40-L19480x36018.7°x14°Auto/manual focus,
NETD <30 mK		30 Hz8 MP-20...+650°C, ±2°C/±2%64 GB5"/12.7 cm 1280x720 LCD touch screen with 90° tilting,
1024x768 OLED viewfinder;
HDMI		ReplaceableGPS,
Wi-Fi, Bluetooth, USB type C,
laser range finder
SP40-L37HM-TP94-Q/W-SP40-L37480x36037.3°x27.8°Auto/manual focus,
NETD <30 mK		30 Hz8 MP-20...+650°C, ±2°C/±2%64 GB5"/12.7 cm 1280x720 LCD touch screen with 90° tilting,
1024x768 OLED viewfinder;
HDMI		ReplaceableGPS,
Wi-Fi, Bluetooth, USB type C,
laser range finder
SP40-L9HM-TP94-Q/W-SP40-L9480x3609°x6.8°Auto/manual focus,
NETD <30 mK		30 Hz8 MP-20...+650°C, ±2°C/±2%64 GB5"/12.7 cm 1280x720 LCD touch screen with 90° tilting,
1024x768 OLED viewfinder;
HDMI		ReplaceableGPS,
Wi-Fi, Bluetooth, USB type C,
laser range finder
SP40-L6HM-TP94-Q/W-SP40-L6480x3606°x4.5°Auto/manual focus,
NETD <30 mK		30 Hz8 MP-20...+650°C, ±2°C/±2%64 GB5"/12.7 cm 1280x720 LCD touch screen with 90° tilting,
1024x768 OLED viewfinder;
HDMI		ReplaceableGPS,
Wi-Fi, Bluetooth, USB type C,
laser range finder
SP40-L9/19HM-TP94-Q/W-SP40-L9/19480x3609°x6.8° and
18.7°x14°		Auto/manual focus,
NETD <30 mK		30 Hz8 MP-20...+650°C, ±2°C/±2%64 GB5"/12.7 cm 1280x720 LCD touch screen with 90° tilting,
1024x768 OLED viewfinder;
HDMI		ReplaceableGPS,
Wi-Fi, Bluetooth, USB type C,
laser range finder
SP40-L9/37HM-TP94-Q/W-SP40-L9/37480x3609°x6.8° and
37.3°x27.8°		Auto/manual focus,
NETD <30 mK		30 Hz8 MP-20...+650°C, ±2°C/±2%64 GB5"/12.7 cm 1280x720 LCD touch screen with 90° tilting,
1024x768 OLED viewfinder;
HDMI		ReplaceableGPS,
Wi-Fi, Bluetooth, USB type C,
laser range finder5
SP40-L19/37HM-TP94-Q/W-SP40-L19/37480x36018.7°x14° and
37.3°x27.8°		Auto/manual focus,
NETD <30 mK		30 Hz8 MP-20...+650°C, ±2°C/±2%64 GB5"/12.7 cm 1280x720 LCD touch screen with 90° tilting,
1024x768 OLED viewfinder;
HDMI		ReplaceableGPS,
Wi-Fi, Bluetooth, USB type C,
laser range finder
SP40-L6/19HM-TP94-Q/W-SP40-L6/19480x3606°x4.5° and
18.7°x14°		Auto/manual focus,
NETD <30 mK		30 Hz8 MP-20...+650°C, ±2°C/±2%64 GB5"/12.7 cm 1280x720 LCD touch screen with 90° tilting,
1024x768 OLED viewfinder;
HDMI		ReplaceableGPS,
Wi-Fi, Bluetooth, USB type C,
laser range finder
SP40H-L19HM-TP94H-Q/W-SP40H-L19480x36018.7°x14°Auto/manual focus,
NETD <30 mK		30 Hz8 MP-40...+2200°C, ±1°C/±1% (0...+150°C) or
±2°C/±2%		64 GB5"/12.7 cm 1280x720 LCD touch screen with 90° tilting, 1024x768 OLED viewfinder, LED ligh; HDMIReplaceableGPS,
Wi-Fi, Bluetooth, USB type C,
laser range finder
SP40H-L37HM-TP94H-Q/W-SP40H-L37480x36037.3°x27.8°Auto/manual focus,
NETD <30 mK		30 Hz8 MP-40...+2200°C, ±1°C/±1% (0...+150°C) or
±2°C/±2%		64 GB5"/12.7 cm 1280x720 LCD touch screen with 90° tilting,
1024x768 OLED viewfinder;
HDMI		ReplaceableGPS,
Wi-Fi, Bluetooth, USB type C,
laser range finder
SP40H-L9HM-TP94H-Q/W-SP40H-L9480x3609°x6.8°Auto/manual focus,
NETD <30 mK		30 Hz8 MP-40...+2200°C, ±1°C/±1% (0...+150°C) or
±2°C/±2%		64 GB5"/12.7 cm 1280x720 LCD touch screen with 90° tilting,
1024x768 OLED viewfinder;
HDMI		ReplaceableGPS,
Wi-Fi, Bluetooth, USB type C,
laser range finder
SP40H-L6HM-TP94H-Q/W-SP40H-L6480x3606°x4.5°Auto/manual focus,
NETD <30 mK		30 Hz8 MP-40...+2200°C, ±1°C/±1% (0...+150°C) or
±2°C/±2%		64 GB5"/12.7 cm 1280x720 LCD touch screen with 90° tilting,
1024x768 OLED viewfinder;
HDMI		ReplaceableGPS,
Wi-Fi, Bluetooth, USB type C,
laser range finder
SP120H-L25HM-TP9CH-W/W-SP120H-L251280x102425°x20°Auto focus,
NETD <20 mK		30 Hz13 MP-40...+2200°C, ±1°C/±1% (0...+150°C) or
±2°C/±2%		128 GB5"/12.7 cm 1920x1080 LCD touch screen with 90° tilting,
1024x768 OLED viewfinder;
HDMI		ReplaceableGPS,
Wi-Fi, Bluetooth, USB type C,
laser range finder

Accessories Overview

TypeModelDescription
LensHM-SP605-LENS0.5x wide angle lens for SP40, SP40H, SP60 and SP60H
LensHM-SP610-LENS1x standard lensfor SP40, SP40H, SP60 and SP60H
LensHM-SP620-LENS2x telephoto lens for SP40, SP40H, SP60 and SP60H
LensHM-SP630-LENS3x telephoto lens for SP40, SP40H, SP60 and SP60H
LensHM-SP620-MACROMacro lens, 20 µm spot size, -20...+150°C, ±2°C/±2%for SP40, SP40H, SP60 and SP60H
LensHM-SP650-MACROMacro lens, 50 µm spot size, -20...+150°C, ±2°C/±2%for SP40, SP40H, SP60 and SP60H
PouchHM-SP01-POUCHSoft pouch with adjustable shoulder strap, with enough space for extra lensfor SP, G and M series cameras
BatteryHM-7250DCBattery 7.2 V, 4300 mAhfor SP series
Battery chargerHM-20322ZCBattery chargerfor SP series battery
Desktop bracketHM-AHBR01Desktop bracketfor SP series

Information on product safety:

Manufacturer:
HIKMICRO Hangzhou Microimage Software Co., Ltd., Building A1, No. 299, Qiushi Road, Tonglu Economic Development Zone, Tonglu County, Hangzhou, Zhejiang/CHN
www.hikmicrotech.com

Datasheet_Hikmicro_SP40H_en.pdf
Datasheet_Hikmicro_SP40_en.pdf
Datasheet_Hikmicro_SP60H_en.pdf
Datasheet_Hikmicro_SP60_en.pdf
