BP backplane for MAL miniature measuring amplifiers

starting 82,11
including VAT plus shipping
min Quantity
1 piece
Unit price
base price
Variants
technical Question?
recommend by email
close
Please fill in all fields.
Question Type
Your E-mail Adress
My Question:
Please validate that you are not a robot.
Description
Accessories
Files/Downloads

Backplane for MAL Miniature Measuring Amplifiers

Up to two or sixteen measuring amplifiers, converters, or any other function modules can be integrated on the BP series. If installed close to the signal, it provides for high interference resistance. Ideal for remote signal conditioning of passive sensors. In type of construction, the cost-effective MAL modules are designed like a 24-pin DIL IC. Measurement applications can therefore be realized even in problematic locations. The great variety of available amplifier modules allows for the solution of the most individual measuring tasks - individual, compact, and simple.

  • 2 or 16 DIL sockets for MAL amplifiers.
  • Connection via screw terminals or, on the BP16, via 37-pin D-sub female.
  • BP2: 9...40 V.
    BP16: 9...30 V.
  • Available as a DIN-rail mountable version, in an IP65 box or in a bmcm system housing.

Model Overview

Model Channels/MAL sockets Housing Size (LxWxH, mm) Power supply Connectors, inputs Connectors, outputs
BP2 2 Board and DIN-rail mountable adaptor 65 x 45 x 35 +9...40 VDC, typ. 0.5 W, max. 1,5 W Screw terminals Screw terminals
BP2-BOX 2 IP65 box, plastic 100 x 85 x 35 +9...40 VDC, typ. 0.5 W, max. 1.5 W Screw terminals Screw terminals
BP16 16 bmcm system housing, IP30 167 x 113 x 30 +9...30 VDC, min. 0.3 W, max. 4 W 37-pin D-sub female 37-pin D-sub female
